Weeder
| Ref.No. | Working width [m] | Power demand [HP] | Number of tines [pcs.] | Weight [kg] | Transport width [m] |
| 8710 | 3.0 | 35 | 96 | 200 | 3,0 |
| 8711 | 4.5 | 40 | 144 | 500 | 3,0 |
| 8712 | 6.0 | 50 | 192 | 620 | 3,0 |
| 8713 | 7.5 | 65 | 240 | 760 | 3,0 |
| 8714 | 9.0 | 90 | 288 | 870 | 3,0 |
Standard equipment
• 3-point linkage cat. I and II for 3m, cat. II for: 4,5m, 6,0m, 7,5m and 9,0m
• Spring tine 7mm with height adjustment
• Transport width of all models up to 3,0m
• Support wheels on bearings (2 pcs for 3m; 4,5m; 6m, 4 pcs for 7,5m and 9m)
• Working depth up to 8cm
• Number of tines 48 pcs (in the working field)
• Working speed up to 10km/h
Optional equipment
• Front spring levelling board
• Spring tine Ø 8mm
• Spring tine Ø 9mm
• Spring tine Ø 10mm
Product number
8710;8711;8712;8713;8714
Description
| Ref.No. | Working width [m] | Power demand [HP] | Number of tines [pcs.] | Weight [kg] | Transport width [m] |
| 8710 | 3.0 | 35 | 96 | 200 | 3,0 |
| 8711 | 4.5 | 40 | 144 | 500 | 3,0 |
| 8712 | 6.0 | 50 | 192 | 620 | 3,0 |
| 8713 | 7.5 | 65 | 240 | 760 | 3,0 |
| 8714 | 9.0 | 90 | 288 | 870 | 3,0 |
